Irregularity Description
The output volume of
THUNDERBEAT can not
be adjusted.
The ultrasonic generator
cannot be turned OFF.
Automatic mist & smoke
Evacuation system/function
does not work.
Cutting/sealing/
coagulating does not work
properly.
ISSUE1
Possible cause
The output volume of
THUNDERBEAT can not be
adjusted with the ultrasonic
generator.
Ultrasonic generator malfunction.
The settings are erroneous.
The communication cable is not
connected.
The connection of the
communication cable is
erroneous.
Compatible high flow insufflation
unit malfunction.
Ultrasonic generator,
communication cable or adapter
for UHI-2/3 malfunction
Operation is not appropriate.
The treated site is not appropriate.
Carbonized tissue is present on the
grasping section or the probe tip.
The output level setting is not
appropriate.
Deterioration of the transducer.
Not activating output.
8-13
Remedial Actions
Adjust the output volume of
THUNDERBEAT with the compatible
electrosurgical generator.
Remove the THUNDERBEAT and/or
SONICBEAT from the body cavity and press
the power switch to OFF. Contact Olympus.
Correct the settings of the compatible high
flow insufflation unit.
Connect the communication
cable. "Automatic mist & smoke
evacuationsystem/function (when using
the compatible high flow insufflation unit)"
Reconnect the communication cable.
"Automatic mist & smoke evacuation
system/function (when using the
compatible high flow insufflation unit)".
Contact Olympus.
Remove the THUNDERBEAT and/or
SONICBEAT from the body cavity and
press the power switch to OFF. Contact
Olympus.
Operate the instrument properly referring to
Chapter 4, "Operation" in the instruction
manual for THUNDERBEAT or SONICBEAT.
Treat the adequate site referring to
Chapter 4, "Operation" in the instruction
manual for THUNDERBEAT or
SONICBEAT.
Remove the carbonized tissue from the
grasping section or the probe tip with sterile
gauze or soft brush.
Set the adequate output level referring to
Chapter 3, "Preparation and Inspection" in
the instruction manual for THUNDERBEAT
or SONICBEAT.
Confirm either whether one year has
passed since the transducer was delivered
or the use of the transducer has exceeded
100 cases. If it is applied to at least one of
them, replace the transducer with a new
one.
Refer to "Energy output cannot be
enerated" of "What to do when no error
code is displayed" in Section 8.3,
"Troubleshooting guide".
USG-400
Troubleshooting
