WEEE Directive
Year of
manufacture
○
Footswitch for THUNDERBEAT (MAJ-1870, optional)/
Footswitch for SONICBEAT (MAJ-1869, optional)
Classification
(medical
electrical
equipment)
Size
○
Communication Cable 0.25m (MAJ-1871, optional)
Size
○
Communication Cable 10m (MAJ-1871, optional)
Size
○
Adapter for UHI-2/3 (MAJ-1873, optional)
Size
Applicable
Cables
○
Docking Fixture (MAJ-1876, optional)
Screws
Hex wrench
Ficture plates
ISSUE1
Degree of water
resistance
Degree of protection
against explosion
Dimensions
Weight
Length of the cord
Weight
Length of the cord
Weight
Length of the cord
Dimensions
Weight
14 pcs
1 pc
2pcs
In accordance with European Directive 2002/96/EC on
Waste Electrical and Electronic Equipment, this symbol
indicates that the product must not be disposed of as
unsorted municipal waste, but should be collected
separately.
Refer to your local Olympus distributor for return and/or
collection systems available in your country.
The last digit of the year of manufacture is given in the
second digit of the serial number.
IEC60529 IPX8 water tight type
(except the plug section)
IEC6060101AP type
346(w)X64(H)X486(D)mm
2.3 kg
4000 mm
0.04kg
250 mm
0.5kg
10,000 mm
94(w)X37(H)X71(D)mm
215 g
MAJ-1871, MAJ-1872
2-3
USG-400
Specifications
