There are three MIDI registered parameters which the S4 plus will recognize in Mix
Play Mode when General MIDI Mode is enabled. These are:
•
MIDI Registered Parameter 0 (Pitch Bend Sensitivity): This will directly effect
the Pitch Wheel Range parameter of all four Sounds of the Program on the
received MIDI Channel of the Mix. If the Channel is selected using the MIDI [¨]
and [Æ] buttons, the word "Edited" will appear next to the Program Number in the
display if this parameter is received. However, if you are viewing the Pitch Wheel
Range parameter in the display (Program Edit Mode, Pitch Function, Page 2,
Quad Knob [2]), the display will not be updated to reflect the new setting. If you
go to another Page or Function and then return to it, the display will now reflect
the updated setting.
•
MIDI Registered Parameter 1 (Fine Tune): This will directly effect the Detune
Amount parameter of all four Sounds of the Program on the received MIDI
Channel of the Mix. If this MIDI registered parameter is received, the S4 will
automatically make sure that all four Sounds of the Program have their Detune
Type parameter set to "Normal" (Program Edit Mode, Pitch Function, Page 1,
Quad Knob [4]). If the Channel is selected using the MIDI [¨] and [Æ] buttons, the
word "Edited" will appear next to the Program Number in the display if this
parameter is received. However, if you are viewing the Detune Amount
parameter in the display (Program Edit Mode, Pitch Function, Page 1, Quad
Knob [3]), the display will not be updated to reflect the new setting. If you go to
another Page or Function and then return to it, the display will now reflect the
updated setting.
•
MIDI Registered Parameter 2 (Coarse Tune):This will directly effect the Tune
Semitone parameter of all four Sounds of the Program on the received MIDI
Channel of the Mix. If the Channel is selected using the MIDI [¨] and [Æ] buttons,
the word "Edited" will appear next to the Program Number in the display if this
parameter is received. However, if you are viewing the Tune Semitone parameter
in the display (Program Edit Mode, Pitch Function, Page 1, Quad Knob [1]), the
display will not be updated to reflect the new setting. If you go to another Page or
Function and then return to it, the display will now reflect the new setting.
(Parts of this appendix are abridged versions of material from Power Sequencing with
Master Tracks Pro/Pro 4 and The Complete Guide to the Alesis HR-16 and MMT-8,
copyright 1990 and 1989 respectively by AMSCO Publications, and is adapted with
permission.)
S4 Plus Reference Manual
MIDI Supplement: Appendix B
129
