Note: The GEN SYNC button cannot be turned on until you have

selected a synchronization type to output. If the GEN SYNC button

is pressed when both the SMPTE and MIDI options are set to Off,

the following display will briefly appear:

Must select output

5.1 TEMPO MAP

The TEMPO MAP button is used to setup the initial time signature

and tempo for the currently selected song. You can also create changes

in tempo and/or time signature at any bar number in the song. This

information is used for:

• Displaying tape position in bars and beats when BARS Display

Type is selected (see section 1.4B); and,

• Generating MIDI CLOCK and Song-Position Pointer information

for synchronizing an external MIDI sequencer or drum machine

(see section 5.0D).

If you are using a static tempo (that is, one tempo and time signature

for the entire song) , you will only need to set the initial tempo and

time signature at bar one. If you require a more sophisticated tempo

map, you may create time signature changes and/or tempo changes at

any bar. The procedure is always the same: first select the song

position in the Tempo Map display where you want to make a

change, then set the tempo and/or time signature. Only the bar

numbers at which changes occur are saved in the tempo map. When

you go back into the Tempo Map display, you can view the

tempo/time signature changes you've created by simply scrolling

through the bars. Deleting a change is done by making its tempo or

time signature the same as the last change that occurred.

Note: Tempo map information for all songs is stored together in the

same location in memory. There are a total of 100 possible tempo

map entries which are shared by the 20 possible songs. Therefore,

the more changes that occur in a tempo map for one song, the

fewer the possible changes available for the remaining songs.

The location of the beginning of a song (Song Start) is selected using

the SET SONG button (see section 4.6A). This determines the tape

position at which bar one occurs.

5.1A Creating A Tempo Map
