1 The CCD color camera XC30
To be able to use the camera, you'll also need the following components:
Other essential
components
1.2
Specifications
Properties of
The XC30 is a cooled, high-resolution CCD color camera used for biomedical and
the XC30
material sciences applications. It was specially developed for acquisitions using light
microscopy.
The XC30 is of a compact design and can be connected to all common types of light
microscope by a C-mount. Its high dynamic range enables it to acquire images
which have both very light and very dark areas. The ICC profile technology
guarantees an optimal color mapping.
Chip type
Chip size
Effective area (width x height)
Pixel size
Maximum resolution
Image type
Read-out speed
Exposure times
Interface
Camera mount
The XC30 has two binning modes. In binning mode, the camera's CCD sensor
Binning modes
combines neighboring pixels into pixel blocks. This results in a higher sensitivity and
a shorter processing time but also in a lower resolution.
Binning
Maximum resolution
Binning 2x
Binning 3x
PC with MS-Windows operating system
Light microscope with camera adapter or something similar, for example a
macro stand
Software to operate the camera (see chapter 3.3 on page 12)
Technical data
Resolution
2080 x 1544 pixels
1040 x 772 pixels
688 x 514 pixels
XC30
CCD
Type 1/1.8 Inch
8.10 mm x 6.64 mm
3.45 µm x 3.45 µm
2080 pixels x 1544 pixels
14-bit color image (RGB)
24.5 MHz
0.1 ms - 160 s
FireWire™IEEE1394a
Standard C-Mount
Frame rate
7.0 images per second
13.6 images per second
35.0 images per second
Specifications
5
