ALESIS
iMULTIMIX 9R
(LXA4)
Service Manual
P/N: 8-31-0185-A
ATTENTION!
THIS DOCUMENT CONTAINS SENSITIVE
PROPRIETARY INFORMATION.
ALL RECIPIENTS MUST HAVE A CURRENT
NON-DISCLOSURE AGREEMENT ON FILE
WITH ALESIS, LLC.
DO NOT MAKE ILLEGAL
COPIES OF THIS DOCUMENT
The information in this document contains privileged and confidential information.
It is intended only for the use of those authorized by Alesis. If you are not the
authorized, intended recipient, you are hereby notified that any review,
dissemination, distribution or duplication of this document is strictly prohibited. If
you are not authorized, please contact Alesis and destroy all copies of this
document. You may contact Alesis at [email protected] or at
Copyright Alesis, LLC
Confidential
Alesis Service Manual
8-31-0185-A

Advertisement

loading
Need help?

Need help?

Do you have a question about the iMULTIMIX 9R and is the answer not in the manual?

Questions and answers

Related Manuals for Alesis iMULTIMIX 9R

Summary of Contents for Alesis iMULTIMIX 9R

  • Page 1 COPIES OF THIS DOCUMENT The information in this document contains privileged and confidential information. It is intended only for the use of those authorized by Alesis. If you are not the authorized, intended recipient, you are hereby notified that any review, dissemination, distribution or duplication of this document is strictly prohibited.
  • Page 2 Your purchase of the Manual shall be for your own ultimate use and shall not be for purposes of resale or other transfer. As the owner of the copyright to the Manual, Alesis does not give you the right to copy the Manual, and you agree not to copy the Manual without the written authorization of Alesis. Alesis has no obligation to provide to you any correction of, or supplement to, the Manual, or any new or superseding version thereof.
  • Page 3 ALL REPAIRS DONE BY ANY ENTITY OTHER THAN AN AUTHORIZED ALESIS SERVICE CENTER SHALL BE SOLELY THE RESPONSIBILITY OF THAT ENTITY, AND ALESIS SHALL HAVE NO LIABILITY TO THAT ENTITY OR TO ANY OTHER PARTY FOR ANY REPAIRS BY THAT ENTITY.

  • Page 4: Safety Instructions

    The product is exposed to water or excessive moisture, c. The AC power supply plug or cord is damaged, d. The product shows an inappropriate change in performance or does not operate normally, or e. The enclosure of the product has been damaged. Confidential Alesis Service Manual 8-31-0185-A...
  • Page 5 Ｒ ＥＶ ＩＳＩＯ Ｎ Ｓ １． ０ Ｆｉ ｌ ｅ　 Ｎ ｏ． Ｐａｇｅ １／１ Ｎ ｏ． Ｅｆｆｅｃｔｅｄ　 ｄａｔｅ Ｒ Ｄ －ＴＤ －０１１ Ｖ ｅｒｓｉ ｏｎ ＳＩＧ Ｎ Ａ Ｔ Ｕ Ｒ Ｅ Ａ ＰＰＲ Ｏ Ｖ ＥＤ Ｒ ＥＶ Ｄ ＩＳＣ Ｒ ＩＰＴ ＩＯ Ｎ Ｄ...
  • Page 6 ALESIS iMULTIMIX 9R (LXA4) SCHEMATIC FILES Confidential Alesis Service Manual 8-31-0185-A...
  • Page 21 ALESIS iMULTIMIX 9R (LXA4) HISTORY Confidential Alesis Service Manual 8-31-0185-A...
  • Page 22 ALESIS iMULTIMIX 9R (LXA4) Confidential Alesis Service Manual 8-31-0185-A...
  • Page 23 LXA4 BOM Date: July 28, 2008 Part Part Name Description Usage Ref. Des. Number RoHS Assembly semi-finished DR000149 LXA4 goods:LXA4 AN-J0130,HF-301RT2,(0.8T) (3P with 40010030 Power Socket fuse) AN-S701,HF-308II6B,(with silkscreen 12070001 Voltage switch 115/230) 12030006 Switch AN-S307,RA12KKET0F,(R19A serial) 12030007 Switch AN-S308,R612KKET0F1,(0.8T) 16060002 GND wire AN-W602,18#,UL1015,120mm...
  • Page 24 DN-PN1001,10*5.4*7.95mm,ABS,,Grey 33 20200001 Switch cap 2 Refer to the photo White DN-MB1011,two side with M2.6 34 10210011 Copper Pole hole,L=14mm,outer 10 Lock panel & front panel diameter:4.75mm(round) Φ8*Φ5.2*1.5mm,Spring steel,nickel 35 70090039 Washer 1 Lock transformer plated 36 70090041 Washer Φ8.5*Φ4.2*0.5,Steel 1 Lock GND plate M2.6*5mm,Cross round head, 37 70010327...
  • Page 25 C7 C8 C71 C52 C34 C21 C76 C81 10uF/25V,±20%,- 61 17020029 Mini E/C C55 C84 C56-58 C60 C62 C36 40/+85℃,Φ4*7mm,P=1.5mm,Black,4mm C39-40 C51 47uF/16V,±20%,- 62 17020048 Mini E/C 2 C90 C97 40/+85℃,Φ5*7mm,P=2.0mm,Black,4mm AN-V10X,Single,05C5K,RV09B-40E1N-215F- 63 15010124 Rotary pot 5 32 R61-62 R93-94 05C5K-A AN-V10T,Single,B5K,RV09B-40E1N-215F- R58 R35 R39 R65-66 R70-71 R89-...
  • Page 26 89 11130038 Carbon resistor 1/8W,820Ω,±5% 1 R6 90 11130046 Carbon resistor 1/8W,1.8KΩ,±5% 2 R171-172 R127-128 R131-134 R179 R182 91 11130047 Carbon resistor 1/8W,2KΩ,±5% R184 R189 R125-126 92 11130048 Carbon resistor 1/8W,2.2KΩ,±5% 1 R10 R95 R72 R69 R140 R100 R141- 93 11130052 Carbon resistor 1/8W,3KΩ,±5% 142 R103 R40...
  • Page 27 RoHS Electronic semi- 117 CR000005 finished 9-40-1302-A(HEADPHONE) goods:XA3(HEADPHONE)board 9-40-1302-A,37.5*12*1.2mm,FR4 Dual FR4 Dual side board, green 118 26020135 side board, green solder mask,10Z solder mask10Z copper copper 119 11170029 SMT resistor 1/10W,240Ω,±5%,0805 4 R4-5, R8, R12 120 11170050 SMT resistor 1/10W,1.8KΩ,±5%,0805 4 R1, R7, R10, R14 121 11170058 SMT resistor...
  • Page 28 144 40190021 RCA Jack AN-J1921,B402A-I,(4P,nickel plated) 1 J4 145 40190083 RCA Jack AN-J1977,RCA-104F, yellow 1 J1 146 40370003 Male Jack AN-JP401,HT-2.54-04P-01A 1 J47 147 40360127 Slot Connect AN-JP319,3P,90 degree 1 J2 One side solder on the first Pin of J15 on rear 148 16140899 Multi-core wire 18#,UL1015,5+200+5mm,Black...
  • Page 29 171 11170048 SMT resistor 1/10W,1.5KΩ,±5%,0805 2 R9, R11 172 11170053 SMT resistor 1/10W,2.2KΩ,±5%,0805 2 R4, R10 173 11170224 SMT resistor 1/10W,3.01KΩ,±1%,0805 4 R5-6, R14, R17 174 11170228 SMT resistor 1/10W,3.32KΩ,±1%,0805 4 R23-26 175 11170258 SMT resistor 1/10W,7.5KΩ,±1%,0805 8 R1-3, R15-16, R18-19, R29 176 50050118 SMT Ceramic Capacitor 221,VDC100,±5%,NPO,0805...
  • Page 30 200 11170067 SMT resistor 1/10W,9.1KΩ,±5%,0805 1 R11 201 11170266 SMT resistor 1/10W,10KΩ,±1%,0805 4 R17, R20-22 202 11170075 SMT resistor 1/10W,18KΩ,±5%,0805 1 R12 203 11170084 SMT resistor 1/10W,47KΩ,±5%,0805 1 R18 204 11170092 SMT resistor 1/10W,100KΩ,±5%,0805 2 R16, R19 205 50050077 SMT Ceramic Capacitor 104,VDC50,+80/-20%,Y5V,0805 4 C1, C3-4, C7 206 14020112...
  • Page 31 231 14040039 L7815CV,TO220,ONSEMI 1 U2 232 14040045 L7915CV,TO220,ONSEMI 1 U3 233 14040213 LM317T,TO220,ST 1 U4 234 10040001 L shape Radiator DN-MH4001,Aluminium alloy 1 Same as XA3(9-03-1180) Lock power supply Board 235 70070018 Outer Hexangular Nut Φ6*M3*3.0mm,Nickel plated Crystal M3*12mm,Cross round head, Lock power supply Board 236 70010128 Screw...
  • Page 32 267 23100130 Giftbox +B3+B3(568*252*210mm)V1.0 LXA4,White print in black,38*26mm,(UPC 268 90040437 Barcode label EAN-13),V1.0 269 90220078 Special lable ALESIS,30*30mm,PANTONE 361C label,V1.0 1 For the first 3 shipment LXA4,white with black 270 90020619 Serial number label printd(128,64*13mm)V1.0 271 22010412 Manual LXA4,multi language...
  • Page 33 291 13020191 Toriod Transformer AN-T20186,100V,40W 1 For JIS 292 90200029 Instruction label LXA4 Black print in white,24*10mm,V1.1 1 For JIS...
