The Specs
Sound Generation Method: sample playback 16 bit Linear 48kHz Sample
ROM
Synthesis: QS Composite Synthesis™
Voices: 64, each with sweepable lowpass filter, 3 envelope generators, 3 LFOs,
programmable effects send and QS Modulation Matrix, dynamic voice allocation
Waveform Memory: 4 Megabytes, 264 samples
Program Memory: 256 presets
Effects: QS Parallel Matrix Effects™ (4 independent stereo multieffect
processing busses)
MIDI Connections: MIDI In, MIDI Out/Thru
Audio Outputs: Stereo Left and Right outputs, 1/4" unbalanced
Power Requirements: 9 VAC, 5 Volt Amps external Transformer, UL and CSA
Approved
Dimensions: (WxHxD) 5.5" x 1.5" x 4.5"
Weight: 1.25 lbs.
What They Mean When They Say "64 Voices"
Once upon a time it was simple. A "voice," in synth parlance, meant a single
note of polyphony. A five voice instrument like the Sequential Circuits Prophet
5™ could play five simultaneous notes. A 16 voice instrument like the Yamaha
DX7™ could play 16 notes. And so on.
Then things got complicated, when synth programmers got deep into digital
design and figured out how to create even more complicated and interesting
–––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
––––––
24
NanoBass Reference Manual
