- Page 1 INSTRUCTIONS Read this manual carefully before using your camera.
- Page 2 WARNING Indicates circumstances under which mishandling resulting from ignoring this symbol could result in personal injury or property damage. KEEP THE BATTERIES AWAY FROM FIRE. NEVER TRY TO DISASSEMBLE, RECHARGE, OR SHORT-CIRCUIT BATTERIES. KEEP THE BATTERIES OUT OF THE REACH OF CHILDREN. IF A CHILD SWALLOWS A BATTERIES, CONTACT A DOCTOR IMMEDIATELY.
- Page 3 DISASSEMBLE THE CAMERA; IT CONTAINS A HIGH-VOLTAGE CIRCUIT. IF THE INTERNAL PARTS OF THE CAMERA ARE EXPOSED DUE TO DROPPING OR DAMAGE, REMOVE THE BATTERIES IMMEDIATELY TO PREVENT FURTHER USAGE. IN CASE OF MALFUNCTION, CONSULT YOUR NEAREST OLYMPUS DEALER OR OLYMPUS SERVICE CENTER.
-
Page 4: Table Of Contents
Names of parts ... 6 Viewfinder display/LCD panel ... 8 Diopter adjustment ... 11 Using the strap ... 11 Loading the battery... 12 Checking the battery ... 14 Proper shutter release ... 15 Loading the film ... 16 Taking pictures ... 19 After shooting... -
Page 5: Table Of Contents
Using the RC-200 remote control (optional)... 45 Printing the date and time**... 49 Correcting the data** ... 51 Visual confirmation finder**... 53 Care and storage... 54 Caring for your weatherproof camera... 58 Specifications ... 61 * Models with the panorama switch only. - Page 6 Shutter release button Zoom lever Viewfinder Light sensor* Strap eyelet Selftimer indicator Lens barrier Remote control sensor* Lens* Autofocus windows* Flash* LCD panel (date/time indicator**) Autofocus auxiliary light* Shooting mode button Self-timer/remote control button...
- Page 7 Viewfinder Diopter adjustment dial Panorama switch*** MODE and SET buttons** Back cover Mid-roll rewind button Tripod socket Battery compartment cover Back cover release Film window Green lamp Orange lamp * Do not soil as this can cause blurred pictures. Wipe clean with a soft cloth.
-
Page 8: Viewfinder Display/Lcd Panel
VIEWFINDER DISPLAY/ LCD PANEL Viewfinder Display Close-up correction marks Autofocus mark Green lamp Orange lamp A: Standard mode B: Panorama mode* * Models with the panorama switch only. The viewfinder will be dark when the battery is depleted. - Page 9 LCD Panel Date/time indicator* Visual Confirmation Finder* Battery Check Night Scene Flash mode Off (Flash Override) mode Fill-In Flash mode Remote control Red-Eye Reduction Flash mode Exposure counter Spot Selftimer/remote control** * QUARTZDATE/DELUXE models only. **Optionally available.
- Page 10 Notes: • If you don't use the camera, the LCD goes off after four and half minutes. • The LCD panel does not actually display all indications simultaneously as shown.
-
Page 11: Diopter Adjustment
DIOPTER ADJUSTMENT Turn the diopter adjustment dial until the viewfinder display becomes clear. Turn to the right if you are farsighted or to the left if you are nearsighted. USING THE STRAP Attach the strap as shown. -
Page 12: Loading The Battery
LOADING THE BATTERY 1. Close the lens barrier. Push OPEN to open the battery compartment cover 2. Insert the new battery correctly. (One 3V lithium battery. CR123A or DL123A) Notes: • Dispose of used batteries in the battery recycling boxes at stores selling batteries. - Page 13 Notes: • About 15 rolls of 24-exposure film can be used with one new battery. • Keep a spare battery on hand when going on a long trip or to a cold area. • Sweat, oil, and so on can prevent a battery's terminals from making electrical contact.
-
Page 14: Checking The Battery
CHECKING THE BATTERY Open the lens barrier until you feel a click. Display: lights (and turns off automatically). Meaning: Battery is OK. You can shoot. Display: blinks and other indicators are displayed normally. Meaning: Battery power is low and battery should be replaced. Display: blinks and other indicators go out. -
Page 15: Proper Shutter Release
PROPER SHUTTER RELEASE Practice before loading the film. 1. Depress the shutter release button halfway to lock the focus. • The green lamp next to the viewfinder lights. 2. Depress the shutter release button fully to release the shutter and take the picture. Cautions: •... -
Page 16: Loading The Film
LOADING THE FILM 1. Open the back cover. Do not touch the inside of the camera, especially the lens. 2. Insert the film cartridge until it clicks. Note: Use of ISO 400 film is recommended. - Page 17 A. Correct Make sure the film is lying flat before closing the back cover. B. Incorrect Push the film cartridge gently to position the film correctly. Then press the left side of the back cover and close it securely. If the film is not lying flat, the film may not advance to the first frame.
- Page 18 3. Align the film leader with the point of the arrow, and close the back cover. The film automatically advances to the first frame. The film does not overlap any of the positioning guides (A). Then close the back cover. 4.
-
Page 19: Taking Pictures
TAKING PICTURES 1. Open the lens barrier until you feel a click. The lens extends slightly, the flash pops up, and the LCD panel turns on. Note: When the flash is held down, the camera will not activate. Release your finger from the flash. - Page 20 2. Aim the camera at your subject. Use the zoom lever for telephoto or wide- angle photography.
- Page 21 How to Use the Zoom Lever Telephoto: Pull the lever to the "T" side to zoom in. Wide angle: Push the lever to the "W" side to zoom out.
- Page 22 3. Position the autofocus mark on your subject. WARNING: SERIOUS EYE DAMAGE MAY RESULT FROM LOOKING DIRECTLY AT THE SUN THROUGH THE VIEWFINDER. 4. Depress the shutter release button halfway to adjust the focus. Focus has been correctly adjusted and the green lamp lights.
- Page 23 5. Depress the shutter release button fully to take the picture. Note: Keep your fingers and the strap away from the lens, autofocus windows and flash. Working distance: 0.8 m (2.6 ft) ~ (infinity) Notes: • When the subject is closer than the minimum working distance, the shutter will not release.
- Page 24 Multi autofocus This camera has a built-in multi autofocus system. With this system, the camera automatically sets the focus on a subject even in compositions where the subject may not be in the center of the frame. Close-up Correction Picture area at (infinity) Close-up correction marks Image area of picture at 0.8 m...
-
Page 25: After Shooting
AFTER SHOOTING 1. Close the lens barrier slowly and carefully. The lens and flash will retract automatically. 2. Close the lens barrier completely. Caution: Do not forcibly close the lens barrier as it will interfere with lens retraction. Note: The power is turned off automatically after 4 hours. -
Page 26: Unloading The Film
UNLOADING THE FILM The camera automatically rewinds the film when you reach the end of a roll. After the motor stops and starts blinking on the LCD panel, open the back cover and remove the film. Rewinding the film before the end of the roll Press the mid-roll rewind button gently with the tip of nail and the... -
Page 27: Taking Panorama Pictures
TAKING PANORAMA PICTURES* Set the switch to PANORAMA. Caution: To avoid malfunction, do not touch the sliding panorama borders inside the camera when the back cover is open in the Panorama mode. Notes: • Always set the panorama switch to either end, not midway between the two ends. - Page 28 • Availability of panorama format film processing facilities varies according to area. We recommend that you consult your local film processor or camera dealer before taking pictures in the Panorama mode. • When pictures taken in the Panorama mode are printed in the standard size, black strips appear at top aand bottom of prints.
- Page 29 Printing the Date and time in the Panorama Mode With this camera, the date and time can be included even in the Panorama mode, but the characters will be slightly larger than normal. For QUARTZDATE/PANORAMA models only. Close-up Correction in the Panorama Mode At about 0.8 m (2.6 ft) (telephoto side), the shaded area in the...
-
Page 30: Using The Flash And Shooting Modes
USING THE FLASH AND SHOOTING MODES This camera has six shooting modes. Use these modes in accordance with the photographic conditions and your purpose. Setting the Modes Each time the shooting mode button is pressed, the mode will change sequentialty as shown on page 31. - Page 31 Auto Flash mode (p. 32) Red-Eye Reduction Flash mode (p. 33) Off (Flash Override) mode (p. 35) Fill-in Flash (Forced Activation) mode (p. 36) Night Scene Flash mode (p. 37) Red-Eye Reduction Night Scene Flash mode (p. 38) Note: The flash strength is automatically controlled to prevent pictures from being overexposed even when the...
- Page 32 Notes: • When the orange lamp is blinking, the flash is being recharged and the shutter won't T (170 mm) W (38 mm) release. Release your finger from 0.8 ~ 5 m 0.8 ~ 1.8 m the shutter release button, and (2.6 ~ 5.9 ft)
- Page 33 RED-EYE REDUCTION FLASH Significantly reduces the phenomenon of "red-eye" (when a subject's eyes appear red in flash photography). In the flash mode, the camera will fire a series of low-power pre- flashes before the regular flash. Red-eye reduction may not be effective when the subject: 1.
- Page 34 The effectiveness of red-eye reduction varies depending on the individual characteristics of subjects. IMPORTANT: Be sure to hold the camera still until the shutter releases. It takes approximately 1 second.
- Page 35 OFF (FLASH OVERRIDE) When you don't want the flash to fire (even in the dark) or when you want to shoot such subjects as fireworks. Use this mode in situations where flash photography is not desired or is prohibited or in twilight or night scenes.
- Page 36 FILL-IN FLASH (Forced Activation) When you want the flash to fire for each shot. The flash fires regardless of available light. Use this mode to compensate for a shadow cast on the subject's face (such as the shadow of a tree). It is also used when shooting in backlit conditions or under artificial lighting (such as fluorescent...
- Page 37 NIGHT SCENE FLASH When taking pictures of a night scene, this mode produces clear images. Notes: • To avoid camera shake, the use of a tripod is recommended since a slow shutter speed (down to approximately 4 seconds) is automatically selected in low- light situations.
- Page 38 RED-EYE REDUCTION NIGHT SCENE FLASH MODE You can take pictures of people with a night scene background while reducing the "red-eye" phenomenon. Notes: • Except for the pre-flashes, this mode is the same as the Night Scene Flash mode. • Read precautionary remarks in "Red-Eye Reduction Flash"...
-
Page 39: Spot Mode
SPOT MODE 1. Press the selftimer/remote control and flash mode buttons simultaneously to enter the Spot mode. The LCD panel displays Press those buttons simultaneously again to cancel the Spot mode. 2. Position the autofocus mark on your subject, and press the shutter release button halfway The green lamp lights. - Page 40 3. Reposition your subject in the picture frame while keeping the shutter release button depressed halfway. Then press the shutter release button fully. After the Spot mode has been engaged or disengaged, check the selftimer/remote control and flash mode settings. Focus and exposure can be adjusted at a different point from the autofocus frame using the...
- Page 41 The use of the Spot mode is recommended in the following cases: • When there is an object in front of the main subject. • When the subject is on the edge of the frame. • When the background is brighter than the subject (the subject is backlit).
- Page 42 In these situations, first focus on a different subject at a similar distance, and then reposition the correct subject in the picture frame. Subjects with low contrast Subjects that do not contain vertical lines Subjects with an extremely bright area in the part of the image Two subjects at different distances...
-
Page 43: Selftimer
SELFTIMER 1. Press the button to display . Fix the camera on a tripod or other support. 2. Aim at your subject, and press the shutter release button. The shutter will be released about 12 seconds after you press the button. The selftimer automatically disengages after release. - Page 44 Notes: • The focus and exposure will be locked when the shutter release button is depressed halfway. • To cancel the selftimer after it has been activated, press the button again.
- Page 45 USING THE RC-200 REMOTE CONTROL (optional) 1. Press the button to display To cancel this mode, press the button again. 2. Aim the remote control at the camera, and press the button. The shutter will be released after about 3 seconds.
- Page 46 WARNINGS: • KEEP THE REMOTE CONTROL OUT THE REACH OF CHILDREN. IF A CHILD SWALLOWS THE REMOTE CONTROL, CONTACT A DOCTOR IMMEDIATELY. • NEVER EXPOSE THE REMOTE CONTROL TO EXCESSIVE HEAT OR OPEN FLAME. Notes: • Use the remote control within a range that can be seen in the viewfinder.
- Page 47 Attaching to the Strap Open the buckle , insert the strap , and close the buckle The remote control can be attached to round straps with a diameter of 3 ~ 5 mm (0.12 ~ 0.2 in) and flat straps with a thickness of 1.2 ~ 2 mm (0.05 ~ 0.08 in) and a width of 6 ~ 12.5 mm (0.24 ~ 0.5 in).
- Page 48 Replacing the Battery 1. Open the buckle remove the battery cover inside by sliding in the direction of the arrow. 2. Insert a new battery (CR1220) with the plus mark showing on top 3. Attach the battery cover by sliding in the direction of the arrow 4.
-
Page 49: Printing The Date And Time
PRINTING THE DATE AND TIME (for QUARTZDATE/DELUXE models only) As you press the MODE button, the mode will switch in the order shown below. No data Year-month-day Month-day-year Day-month-year Day-hour-minute... - Page 50 The quartzdate uses the same power source as the main unit. Make sure to correct the data after the battery is replaced. The data is imprinted in the lower right corner of the picture. When there are bright colors like white, orange, yellow, etc., the data may be difficult to read.
- Page 51 CORRECTING THE DATE (for QUARTZDATE/DELUXE models only) 1. Keep the MODE button depressed to bring the year indication to blinking. The year indication will start blinking. Do not use an instrument with a sharp tip. 2. Press the SET button to correct the year.
- Page 52 3. Press the MODE button again. The month indication will start blinking. 4. Repeat pressing of the SET and MODE buttons until the hours and the minutes have been set. 5. Press the MODE button for completion. • The indication becomes "year- month-day".
-
Page 53: Visual Confirmation Finder
VISUAL CONFIRMATION FINDER (for DELUXE model only) This camera incorporates a shutter release visual confirmation function. This momentarily darkens the viewfinder during shutter release to provide you with confirmation that the shutter has been released. If you do not want to use this function, keep the SET button pressed until the VF indication goes out (5 sec or more). -
Page 54: Care And Storage
CARE AND STORAGE • Do not leave the camera in any place exposed to excessive heat, humidity, or direct sunlight — for example, in a car or on the beach. • Do not expose the camera to formalin or naphthalene. •... - Page 55 • Do not expose the camera to dust or sand as this could cause serious damage. • Do not shake or shock the camera. • Do not apply excessive force to the zoom lens. • Keep the camera in a well- ventilated place.
- Page 56 • When transporting the camera from a cold place to a warm place or in the event of a sudden temperature change, put the camera into a plastic bag. This allows the camera's temperature to change slowly. Once the camera has adjusted to the new temperature, you can remove it from the bag and use it.
- Page 57 • Avoid leaving the camera unused for long periods of time. This can cause mold to grow on the camera as well as other problems. Try to press the shutter release button and check the operation of the camera before use. •...
-
Page 58: Caring For Your Weatherproof Camera
CARING FOR YOUR WEATHERPROOF CAMERA This camera is designed to be water- resistant; however, it is not designed for underwater use or to be subjected to being saturated. Seawater can be especially damaging to your camera due to salt content. Note the following warnings and take the necessary precautions if your camera becomes wet. - Page 59 These gaskets protect the interior of the camera from becoming wet in the event the camera is splashed with water. Check these gaskets often and carefully remove any sand or dust to maintain this protective seal. Whenever your camera gets wet, take the following precautions to maintain your camera in good working order.
- Page 60 They may need more frequent replacement depending on use and wear. If the gaskets are damaged or need replacement, contact your nearest Olympus service center. If you are taking pictures at the beach, you need to avoid getting sand on or inside of your camera.
-
Page 61: Specifications
38 ~ 170 mm zoom lens. Film format: 35 mm standard DX- coded film (24 x 36 mm). Lens: Olympus lens 38 ~ 170 mm F4.8 ~ 13, 10 elements in 8 groups. Shutter: Programmed electronic shutter. - Page 62 Focusing: Advanced combination auto focus system. Focus lock possible. Focusing range — 0.8m (2.6 ft) ~ (infinity). Exposure control: Programmed automatic exposure control, 3-zone light metering, switchable to spot metering. Auto exposure range: Wide angle — EV 2.6 (F4.8·4 sec.) ~ E V 16 (F12.8·1/400sec.);...
- Page 63 Remote control (optional): Infrared remote control unit with approx. 3-sec. delay. Film speed range: Automatic setting with DX-coded film with ISO 50, 100, 200, 400, 800, 1600 and 3200. Film speeds other than above will be automatically set to next lower speed. For non- DX-coded film and film with less than ISO 50, film speed is set to ISO 100.
- Page 64 Film loading: Automatic loading. (Automatically advances to first frame when camera back cover is closed.) Film advance: Automatic film winding. Film rewind: Automatic film rewind (automatic rewind activation at end of film, automatic rewind stop). Rewind possible at any point with rewind button.
- Page 65 Flash: Built-in flash. Recycling time: Approx. 0.5 ~ 5.5 sec. (at normal temperature with new battery). Flash working range: Wide angle — 0.8 ~ 5 m (2.6 ~ 16.4 ft)/ Telephoto — 0.8 ~ 1.8 m (2.6 ~ 5.9 ft) with ISO 100 color negative film;...
- Page 66 Battery check: Displayed on LCD panel. Power source: One 3 V lithium battery (DL123A/CR123A). Dimensions: 123 (W) x 66.5 (H) x 50 (D) mm (4.8 x 2.6 x 2.0 in) (without protrusions). Weight (without battery): 275 g (9.7 oz).
- Page 67 SPECIFICATIONS FOR DATE UNIT Imprinting direction: Data imprinted onto film from lens side. Data coding: No data, year- month-day, month-day- year, day-month-year and day-hour-minute. External indication of data: Data display on LCD panel Automatic calendar system: Up to year 2035. Power source: Ordinarily used with camera body.
- Page 68 SPECIFICATIONS FOR RC-200 REMOTE CONTROL (optional) Type: Infrared type remote control. Operating range: Approx. 5 m (16.4 ft). Battery: One CR1220, replaceable; service life — approx. 5 years or approx. 20,000 operations. Dimensions: 32 x 44 x 13 mm (1.3 x 1.7 x 0.5 in). Weight: 11 g (0.4 oz) (without battery).
- Page 69 OLYMPUS OPTICAL CO., LTD. Two Corporate Center Drive, Melville, NY 11747-3157, U.S.A. Tel. 1-800 "O" CAMERA(622-6372) OLYMPUS AMERICA INC. OLYMPUS OPTICAL CO. (EUROPA) GMBH. OLYMPUS SINGAPORE PTE. LTD. OLYMPUS KOREA CO., LTD. This device complies with part 15 of the FCC Rules. Operation is subject to the conditions that this device does not cause harmful interference.
